1 Safety Information

1.1 Dangers

There are no dangers that refer to the product in general. Specific “Danger” statements may be given in the respective sections of this operation manual.



1.2 Warnings



2 3
4 5 6
7 8 9

1.3 Cautions

● MOUNTING THE MEDICAL ELECTRICAL EQUIPMENT

Only when all screws are tightened and securely fixed can the ME equipment be mounted.

1.4 Note

Note

● Please select the corresponding machine installation according to the model of medical equipment.

2 Equipment Symbols

NOTE

● Some symbols may not appear on all equipment.

Attention: Consult accompanying documents (this manual).

Serial number

Read Operators Manual

CE mark

Manufacturer

Importer

Manufacture date

Medical Device

3 Area of application/ Intended use

CORITON Medical Equipment Roll Stand are intended to mount and position medical electrical equipment (hereafter referred to as ME equipment) and accessories to those and are used in operating theaters as well as treatment rooms as auxiliary devices for doctors and medical staff.

4 Reporting obligation

Reporting obligation

Any serious incident that has occurred in relation to the device should be reported to the manufacturer and the competent authority of the Member State in which the user and/or patient is established.

5 Name of manufacturer

CORITON INSTRUMENT CO., LTD.

Add: 5F Building C, Gold Power Industry Park,

Julongshan Grand industrial Zone, Pingshan Dist.,

Shenzhen, China 518118

Tel : +86 755 89581055 Email: info@coriton.com

6 CE Mark

7 EU Authorized Representative

Umedwings Netherlands B.V.

ADD:Treubstraat1,2288EG,Rijswijk, The Netherlands

Tel: +31 (0) 642758955 Email: ar@umedwings.eu

8 Manual Safekeeping

For any questions that may arise at a later time please safe-keep our manual!

9 Specification

9.1 Hardware Specifications

Model

RS011E-08831




Brand

CORITON

Load Capacity

7 Kg

Trolley Size

520*520*1000mm

Height

1000mm

Basket

300*213*150mm, Plastic,

White color as standard ,

Adjust Way

Fixed Height 1M

Material

Aluminum alloy+Sheet metal+ABS

Package Size

80*80*20cm (2PCS in 1 Carton)

Net Weight

10kg (2 PCS)

5Kg (1PCS)

Gross Weight

13kg (2 PCS)

Certificates

ISO9001/RoHS/FDA/ISO13485

9.2 Environmental Specifications

Temperature range

Operating

0 ºC ~+40 ºC

Storage

-40ºC~+70ºC

Humidity range

Operating

15% – 95 %,non-condensing

Storage

10% – 95 %,non-condensing

Altitude range

Operating

-500 ~ +4,600 m (57.0kPa~106.0kPa)

Storage

-500 ~ + 4,600 m (50.0kPa~106.0kPa)
